230V programmable room thermostat heating units with white backlight

FOB Reference Price:Get Latest Price
$1.00 - $20.00 / Pieces | 200 Piece/Pieces (Min. Order)
Material:
Anti-flammable PC +ABS
Lead Time:
Quantity(Pieces) 1 - 500 >500
Est. Time(days) 15 Negotiable
Report Suspicious Activity
Overview
Quick Details
Color:
white
Place of Origin:
Fujian, China
Brand Name:
HYSEN
Model Number:
HY03WE-1
Type:
Floor Heating Systems, Heating thermostat
Application:
Used for under floor heating
Size:
86*86*30mm
Power Supply:
AC 230V 50/60Hz
Function:
temperature control
Programmable:
5+2 days
Contact capacity:
16A
Set point range:
5~35 °C
Accuracy:
±0.5°C
Certifications:
CE RHOS
Supply Ability
Supply Ability:
10000 Piece/Pieces per Month thermostat
Packaging & Delivery
Packaging Details
Standard packing or customized
Port
Xiamen,China
Lead Time :
Quantity(Pieces) 1 - 500 >500
Est. Time(days) 15 To be negotiated
Product Description
HY03WE-1 is digital programmable thermosat ,use for controlling heating films ,heating mat ,IR panel etc .to ensure
comfortable room temperature and save electrical bill.

Technical Date

Power supply
AC230V,50/60Hz
Max Current
16A
Display accuracy
0.5°C
Setting temp range
5-35°C
Output
Switch relay
Sensor
NTC
Programmable
5+2 days
Size
86*86*30mm
Backlight
White
Wiring Diagram

1&2 connect load (such as heating films),3 connect N line,4 connect L line. 5&6 connect external sensor
